SiT8008

频率	1 to 110 MHz
频率Stability (ppm)	±20, ±25, ±50
Phase Jitter (rms)	1.3 PS.
Output Type	lvcmos.
Operating Temperature Range (°C)	-20 to +70, -40 to +85
FlexEdge.TM值上升/下降时间	是
Voltage Supply (V)	1.8, 2.5 to 3.3, 1.8 to 3.3 (sampling)
包类型(毫米²)	2.0x1.6, 2.5x2.0, 3.2x2.5, 5.0x3.2, 7.0x5.0
特征	Field programmable
Availability	Production

Configurable feature sets

• Any frequency between 1 and 110 MHz with 6 decimal places of accuracy
• 稳定性为±20 ppm至±50 ppm
• 工业或扩展商业温度。
• 1.8 V，2.5 V至3.3 V，1.8 V至3.3 V（采样）电源电压：
• Customize specification for optimal system performance
• Use same base device for many designs, reducing qualification needs;

Small 2016 & 2520 packages for all frequencies, voltages and stabilities

• 在不影响性能和可用性的情况下保存更多的电路板空间

Low power consumption

• 1.2 µA typical standby current (1.8 V)
• 3.6 mA typical active current (1.8 V):
• Extends battery life in portable applications
• Reduces power consumption for greener systems;

FlexEdge™可配置驱动强度

• 从振荡器最小化EMI的速度升高/下降时间
• 通过驱动多个负载来节省成本并消除额外的定时组件;

Ultra-fast lead time (4 to 6 weeks)

• Reduce inventory overhead
• Mitigate shortage risks
